RV REVIEW
THE SPECIFICATIONS
WILL IT FIT IN YOUR GARAGE?
Overall length: 7.94m External body length: 5.53m External width: 2.5m Travel height: 3.2m Internal height: 2m
WEIGHTS Tare: 2830kg GTM: 3271kg ATM: 3500kg Unladen ball weight: 156kg
INTERNAL Cooking: Portable induction only Refrigeration: 224L compressor Microwave: Yes Shower: Separate cubicle Heating: No( reverse-cycle AC only) Toilet: Cassette Washing machine: Front-loader Lighting: LED
Entertainment: 28in flatscreen smart TV; sound system with internal and external speakers
EXTERNAL
Construction: RXP 2.0 fibreglass sandwich panel walls with side protection, one-piece composite roof and 18mm high density composite floor system
Coupling: DO35
Chassis: Flat-floor truss chassis and 6in A-frame with 500mm extension
Suspension: ARV Titan X 3500kgrated independent coil
Brakes: 12in electric Wheels: 16in alloy Fresh water: 2x110L with fast-fill point Grey water: 1x110L Shower: No Awning: Manual wind-out Entertainment locker: Yes
Battery: Chassis-mounted DCX 12V 628Ah with 3000W Projecta inverter, Intelli-Grid power management system and DC-DC charger
Solar: 880W
Air-conditioner: Dometic Series 7 reverse-cycle
Gas: 2x9kg Bike rack: No Sway control: Yes
OPTIONS FITTED TO THIS VAN
Retreat Caravans 20th Anniversary Pack
PRICE AS SHOWN RRP: $ 147,000
