RV REVIEW
THE SPECIFICATIONS
WILL IT FIT IN YOUR GARAGE?
Overall length: 9.17m External body length: 6.57m External width: 2.37 Travel height: 3.02 Internal height: 2m
WEIGHTS Tare: 3045kg GTM: 4347kg ATM: 4500kg( 3500kg is standard) Unladen ball weight: 153kg
EXTERNAL
Construction: Fibreglass sandwich panel with‘ honeycomb’ floor
Coupling: DO35 / DO45( depending on ATM)
Chassis: 6in hot-dippedgalvanised with aluminium subframe
Suspension: Independent airbag Brakes: 12in electric Wheels: 17in alloy
Fresh water: 270L with integrated water management manifold
Grey water: 87L
Shower: Yes – multiple outlets with portable shower hose
Awning: Roll-out
Battery: 920Ah lithium with 3000W / 120A Victorn inverter / charger
Solar: 1760W Air-conditioner: Reverse-cycle Gas: 2x9kg Bike rack: Optional
Kitchen: Yes, with portable induction hotplate
Sway control: No
INTERNAL Cooking: Electric induction Refrigeration: 274L compressor
Microwave: NCE 3-in-1( microwave, air-fryer and griller)
Shower: Hand-held
Heating: Truma Combi diesel water / space heater
Toilet: Compositing with separate 14L urine holding tank
Washing machine: Front-loader Lighting: LED
OPTIONS FITTED TO THIS VAN
4500kg ATM upgrade
PRICE AS SHOWN
$ 200,980 From $ 199,990
