RV PROFILE
THE SPECIFICATIONS
WILL IT FIT IN YOUR GARAGE ?
Overall length : 9.04m External body length : 6.57m
External width : 2.33m ( excluding awning )
Travel height : 3.12m Internal height : 1.99m
WEIGHTS Tare : 3181kg ATM : 4000kg GTM : 3721kg Axle group capacity : 4000kg Unladen ball weight : 279kg
EXTERNAL
Body structure : Composite fibreglass roof , floor and walls
Coupling : Cruisemaster DO45
Chassis : Aluminium 6in with raiser ; 6in drawbar
Suspension : 4000kg-rated Control Rider airbag
Brakes : Disc brakes Wheels : 17in alloy Fresh water : 2x95L ; 1x65L Grey water : 1x65L Awning : Electric
Battery : Chassis-mounted DCX 14.3kWh with 5kW inverter
Solar : 4x400W
Air-conditioner : Houghton Belair 3400 roof-mounted reverse-cycle
Gas : None ( not necessary ) Sway control : AL-KO ESC
INTERNAL
Cooking : Safiery 2000W induction hob ; external Weber Electric Pulse with separate induction cooktop
Refrigeration : Thetford 174L compressor fridge-freezer
Microwave : Yes
Shower : Fibreglass separate cubicle
Toilet : Sun-Mar composting toilet
Washing machine : Daewoo 2kg wall-mounted
Lighting : 12V LED Hot water : Swift ( electric only )
Entertainment : Rockford Fosgate stereo system with four speakers
