RV FEATURE
THE SPECIFICATIONS
POWERTRAIN
Engine: Four-cyclinder 3L turbodiesel
Max power: 140kW at 3600rpm
Max torque: 450Nm between 1600 and 2600rpm
Transmission: Six-speed automatic with sequential shift and brake shift lock
DIMENSIONS AND WEIGHTS
Length: 4.86m Width: 1.87m Wheelbase: 2.86m
Wheels: 17in alloy( LS-M); 18in alloy( LS-U); 20in alloy( LS-T and X-Terrain)
Ground clearance: 230mm( LS-M); 235mm( all other models)
Kerb weight: 2050kg( LS-M 4x2) to 2195kg( X-Terrain)
Gross Vehicle Mass: 2700kg( all 4x2 models); 2800kg( all 4x4 models)
Gross Combined Mass: 5900kg( all models)
Towing capacity: 3500kg Maximum towball mass: 350kg
CHASSIS AND SUSPENSION
Chassis: Ladder frame with nine cross-members
Front suspension: Independent 4x4 fully floating with outer CV, inner double offset joints and qual length driveshafts; rating: 1450kg
Rear suspension: Rigid semifloating banjo with hypoid final drive and dual tapered needle roller bearings; rating: 1650kg
Brakes: 320mm ventilated discs( front); 295mm drums( rear)
OTHER Fuel tank capacity: 80L Wading depth: 800mm Warranty: Six years / 150,000km
Servicing: Five years’ flat price when serviced through IUA dealers
PRICE
$ 50,400( LS-M 3L 4x2) to $ 74,400( X-Terrain 4x4)
